Description
Long Range 100m LiDAR Laser Rangefinder Accurate Distance Ranging Sensor TF03-100 RS485/RS232 for Vehicles Anti-Collision Obstacles Detection
As the third generation product of the TF series, TF03-100 inherits the cost-effective and compact integration characteristics of the previous two generations. Meanwhile, TF03-100 upgrades more than ten key parameters and offers multiple expansion functions to meet the demands of various applications. The product applies to the terrain-following of drones, the collision avoidance of cars, intelligent transportation, and industrial safety warnings.
- Long-range, as far as 100m
- Multi-interface compatibility, able to be used in many fields
- IP67 high-strength bodywork and high reliability
- Small in volume and easy to integrate
- High-speed measuring up to 10 KHz, high repeatability accuracy
- Excellent highlight interference, able to be used outdoors
- RS485/RS232 version
TF03 uses the pulse method to range the distance based on TOF (Time-of-Flight). Specifically, TF03-100 emits a beam of light, which will be reflected by the object and received by TF03-100 again.
- Long Range: 100m@90% reflectivity , 40m@10% reflectivity
- Blind Zone: 10cm
- Distance resolution: 1cm
- Accuracy: ±10cm (within 10 m), 1% (beyond 10m)
- Repeatability 1σ: 3cm
- Output frame rate: 1Hz-1000Hz (Default 100Hz)
- Multi echo: 4 times
- Ambient Light Resistance: 100Klux
- Over range output: 100m (Default)
- RS485/RS232 interface
Typical Applications
- Robot Obstacle Avoidance
- UAV Anti-collision
- UAV Auto landing
- UAV Height fixing / Distance-keeping
- UAV Terrain following
- Level Measurement
- Intelligent parking
- Crane safety operations
- Vehicle position sensing
- Vehicle detection for barrier gate control
